OREN-AC400V-7KW Rack Mounted Load Bank
OREN-AC400V-7 KW-R ac load bank is suitable for on-load testing in data center room
OREN-AC400V-7KW Rack Mounted Load Bank
一、General Introduction OREN-AC400V-7 KW-R ac load bank is suitable for on-load testing in data center room. Use local manual control, with short circuit, and over-temperature protection functions.
二、Technical Parameters
|
Model |
OREN-AC400V 7KW |
|
Rated Voltage |
3P AC400V/1P 230V |
|
Rated Power |
7KW |
|
Load Step |
500W/500W/1KW/1KW/2KW/2KW |
|
Control Mode |
Manual Circuit Breaker Control |
|
Input interface |
C20 Socket |
|
Air Temperature |
from 6℃ to 20℃ (optional function ) |
|
Control switches |
ABB |
|
Fan cooling |
Forced air cooling , front inlet air，rear outlet air |
|
Color |
Black |
|
Size |
L*W*H :65.5*48.5*26.6 (cm) |
|
Net Weight |
About20KGS |
|
Accessories Cable |
C19-C20 1.5M 6PCS for each unit 3PIN C19-5PIN 32A 3M 2PCS for unit (optional)
|
